Hør hver eneste detalj med Universal Audios mest avanserte Apollo Twin noensinne. Med høyoppløselig lydkonvertering, Unison™ mikrofonforforsterkere og sanntids UAD-behandling – som lar deg ta opp gjennom plug-ins fra Neve, API, Manley, Auto-Tune og mer uten forsinkelse – Apollo Twin X setter tiår med inspirerende analogt studio lyd rett på skrivebordet.
- 10 x 6 Thunderbolt lydkort med DUO eller QUAD Core DSP plug-in prosessering
- To Unison™ mikrofonforforsterkere, Hi-Z instrumentinngang, optisk Toslink-inngang (ADAT eller S/PDIF)
- To 1/4" monitorutganger, to 1/4" linjeutganger (ALT), en 1/4" TRS hodetelefonutgang
- Eliteklasse Apollo X Gen 2 konvertere med 24-bit / 192 kHz oppløsning
- Forbedret D/A for kritisk monitoring og avspilling med 129 dB dynamisk område
- Kalibrer hovedmonitorene og hodetelefonutgangene dine med Apollo Monitor Correction drevet av Sonarworks®
- Fullt utstyrt monitorkontroller med alternativ høyttalerbytte og integrert talkback for enkel kommunikasjon med artisten
- Oppdatert UAD Console-app med Auto-Gain, Plug-In Scenes, subwoofer-integrasjon med Bass Management, støtte for immersive lyd og mer
- Onboard DSP støtter over 200 UAD plug-ins via VST, AU og AAX 64-formater i alle større DAW-er
- Inkluderer opptil 50+ UAD-plugin-moduler med Essentials+ eller Studio+ Editions
- Kompatibel med LUNA, Logic Pro, Pro Tools, Cubase, Ableton Live og mer*
- Kan utvides med Thunderbolt Apollo-lydkort eller utvalgte modeller over Dante
- Gratis bransjeledende teknisk støtte fra kunnskapsrike lydteknikere
SYSTEM |
|
|---|---|
| I/O Complement | |
| Simultaneous Channel I/O Count (analog + digital) | 10 x 6 (ADAT mode) |
| Microphone Inputs | Two |
| High Impedance (Hi-Z) Instrument Inputs | One |
| Analog Line Inputs | Two |
| Analog Line Outputs (DC coupled) | Two (four including Monitor outputs) |
| Analog Monitor Outputs (DC coupled) | Two (one stereo pair) |
| Headphone Output | One stereo |
| Digital Audio Port (ADAT or S/PDIF, selectable) | One input |
| Thunderbolt 3 Port* | One |
| *(Mac only) Thunderbolt 1 and 2 connections supported via Apple Thunderbolt 3 to Thunderbolt 2 adapter | |
| A/D – D/A Conversion | |
| Simultaneous A/D conversion | Two channels |
| Simultaneous D/A conversion | Six channels |
| Available Sample Rates (kHz) | 44.1, 48, 88.2, 96, 176.4, 192 |
| Bit Depth Per Sample | 24 |
| Analog Round-Trip Latency | 1.1 milliseconds @ 96 kHz sample rate |
| Analog Round-Trip Latency through four UAD legacy plug-ins (included) via UAD Console software | 1.1 milliseconds @ 96 kHz sample rate (no additional latency via Realtime UAD Processing) |
ANALOG I/O |
|
| Microphone Inputs 1 & 2 | |
| Frequency Response | 20 Hz – 20 kHz, ±0.04 dB |
| Dynamic Range | 123 dB (A–weighted) |
| THD + Noise (1 kHz @ 24 dBu, -1 dBFS) | -115 dB (0.00018%) |
| Maximum Input Level (PAD on) | 25 dBu |
| Default Input Impedance (variable via Unison plug-ins) |
5.4 K Ω |
| Gain Range | +10 dB to +65 dB |
| Pad Attenuation (switchable per mic input) |
20 dB (variable via Unison plug-ins) |
| Phantom Power (switchable per mic input) |
+48V |
| Connector Type | XLR Female, pin 2 positive (Combo XLR/TRS) |
| Hi-Z Input (600 K Ω input termination) | |
| Frequency Response | 20 Hz – 20 kHz, ±0.05 dB |
| Dynamic Range | 121 dB (A–weighted) |
| THD + Noise (1 kHz @ 11.4 dBu, -1 dBFS) |
-110 dB (0.00032%) |
| Maximum Input Level (at minimum gain) |
12.4 dBu |
| Default Input Impedance (variable via Unison plug-ins) |
1 M Ω |
| Gain Range | +10 dB to +65 dB |
| Connector Type | ¼" Female TS Unbalanced |
| Line Inputs 1 & 2 | |
| Frequency Response | 20 Hz – 20 kHz, ±0.04 dB |
| Dynamic Range | 122 dB (A–weighted) |
| THD + Noise (1 kHz @ 19.2 dBu, -1 dBFS) |
-115 dB (0.00018%) |
| Maximum Input Level (reference level @ +4 dBu) |
20.2 dBu |
| Input Impedance | 10 K Ω |
| Gain Range | +10 dB to +65 dB |
| Connector Type | ¼" Female TRS Balanced |
| Line Outputs 1 & 2 | |
| Frequency Response | 20 Hz – 20 kHz, ±0.01 dB |
| Dynamic Range | 127 dB (A–weighted) |
| THD + Noise (1 kHz @ 19.2 dBu, -1 dBFS) |
-119 dB (0.00011%) |
| Maximum Output Level Reference level @ +4 dBu Reference level @ -10 dBV |
20.2 dBu 14.5 dBu |
| Output Impedance | 100 Ω |
| Connector Type | ¼" Female TRS Balanced |
| Monitor Outputs L & R | |
| Frequency Response | 20 Hz – 20 kHz, ±0.04 dB |
| Dynamic Range | 129 dB (A–weighted) |
| THD + Noise (1 kHz @ 19.2 dBu, -1 dBFS) |
-120 dB (0.0001%) |
| Maximum Output Level | 20.2 dBu |
| Output Impedance | 100 Ω |
| Connector Type | ¼" Female TRS Balanced |
| Stereo Headphone Outputs | |
| Frequency Response | 20 Hz – 20 kHz, ±0.01 dB |
| Dynamic Range | 124 dB (A–weighted) |
| THD + Noise 300 Ω load (1 kHz @ 14.4 dBu, -1 dBFS) 600 Ω load (1 kHz @ 14.8 dBu, -1 dBFS) |
-112 dB (0.00025%) -114 dB (0.00019%) |
| Maximum Output Level 300 Ω load (1 kHz @ 14.4 dBu, -1 dBFS) 600 Ω load (1 kHz @ 14.8 dBu, -1 dBFS) |
15.4 dBu 15.8 dBu |
| Maximum Output Power (RMS) 300 Ω load (1 kHz @ 14.4 dBu, -1 dBFS) 600 Ω load (1 kHz @ 14.8 dBu, -1 dBFS) |
69 mW 38 mW |
| Connector Type | ¼" Female TRS Stereo |
DIGITAL INPUT |
|
| Digital Audio Port (ADAT or S/PDIF, selectable) |
One input |
| Connector Type | Optical TOSLINK JIS F05 |
| S/PDIF | |
| S/PDIF Channels | One stereo input |
| Format | IEC 958 |
| Supported Sample Rates (kHz) | 44.1, 48, 88.2, 96 |
| ADAT | |
| ADAT Channels | Up to eight input channels |
| Format | ADAT Lightpipe with S/MUX |
| Supported Sample Rates (kHz) | 44.1, 48, 88.2, 96, 176.4, 192 |
| Channel Assignments @ 44.1 kHz, 48 kHz | Channels 1 – 8 |
| Channel Assignments @ 88.2 kHz, 96 kHz | Channels 1 – 4 |
| Channel Assignments @ 176.4 kHz, 192 kHz | Channels 1 – 2 |
| Clock Synchronization Sources | |
| Internal, ADAT, S/PDIF | Conditional per selected digital input type |
ELECTRICAL |
|
| Power Supply | External AC-to-DC Power Supply, Level VI compliant |
| AC Input Connector | Type IEC C8, non-polarized |
| AC Requirements | 100V – 240V AC, ≈ 50 – 60 Hz, 1.2 A MAX |
| DC Connector Type | Male barrel plug, 2.1 mm x 5.5 mm, center positive |
| DC Requirements | 12 VDC, ±5% |
| Maximum Power Consumption | 15 Watts (when portable host computer not charging) |
ENVIRONMENTAL |
|
| Ambient Temperature Range | 32º to 104º F (0º to 40º C) |
MECHANICAL |
|
| Dimensions | |
| Width | 6.31" (160.34 mm) |
| Height | 2.59" (65.81 mm) |
| Depth, Chassis Only | 5.89" (149.59 mm) |
| Depth, Including Knob & Jack Protrusions | 6.14" (156.10 mm) |
| Shipping Box (Length x Width x Height) |
6" x 8" x 8" (152 mm x 203 mm x 203 mm) |
| Weight | |
| Shipping Weight (with box & accessories) |
4.37 pounds (1.98 kg) |
| Weight (bare unit) | 2.29 pounds (1.04 kg) |
| Package Contents | |
| Apollo Twin X Gen 2 Audio Interface (DUO or QUAD) | |
| External Power Supply | |
| AC Power Cable (IEC C7, non-polarized) | Region Specific (USA, EU, UK, ANZ, or Japan) |
| Getting Started URL Card | |
